Produktinformationen "TID050TT07-3|Tungaloy"
Exchangeable head drill,L/D=3,TinyMini-Turnadaptation
Eigenschaften
| Application: | General Drilling |
|---|---|
| Tool Type: | indexable head drills |
| Body Material: | Steel |
| group_id: | 6215 |
| FamilyName: | TID-TT L/D=3 |
| product_pic: | 2889 |
| product_drw: | 2889 |
| ToolType: | Tool |
| Längen/Durchmesser Verhältnis: | 3xD |
| Unit: | M |
| FamilyPriority: | 41 |
| PackSize: | 1 |
| PricePer: | 1 |
| fixed_lot_multiplier: | 1 |
| product_code: | TUN7769131 |
| ProductName: | TID050TT07-3 |
| COO: | JAPAN |
| UOM: | EA |
| hazard_material: | 0 |
| oversize_product: | 0 |
| UNSPSC: | 23242106 |
| FamilyDesc: | Exchangeable head drill,L/D=3,TinyMini-Turnadaptation |
| FamilyShortDesc: | Exchangeable head drill,L/D=3,TinyMini-Turnadaptation |
| Vendor: | 30 |
| Link: | https://www.imc-companies.com/Tungaloy/tcat/e.asp?cat=7769131 |
| Movie: | https://www.youtube.com/watch?v=ss9-DmLz6H0 |
| Produktlinie: | DrillMeister |
| LogoName2: | AddForceDrill |
| LogoPic1: | 660 |
| Remarks: | Note: An overall length depends on the type of drill head which is mounted on. |
| LogoName3: | TinyMiniTurnMulti |
| LogoPic2: | 686 |
| StockSource: | IMC |
| FamilyBrand: | Tungaloy |
| BrandCode: | TUN |
| BrandName: | Tungaloy |
| LogoPic3: | 1592 |
| APP1: | 650 |
| APP1Name: | General Drilling |
| DXF: | 7769131 |
| ItemRemark: | The clamping key is supplied with the drill head. |
| STP: | 7769131 |
| STPL: | 7769131 |
| Measurement Type: | Metric |
| Connection Diameter Machine Side (DCONMS): | 7 mm |
| Package Weight: | 0.0000 |
| MSDS: | 07995 |
| LocalField1: | 2 |
| ManufacturerNo: | 7769131 |
| Master Insert Identification (MIID): | DMP050 |
| Overall Length (OAL): | 41.3 mm |
| Cutting Diameter Maximum (DCX): | 5.49 mm |
| Cutting Diameter Minimum (DCN): | 5 mm |
| Insert Seat Size Code (SSC): | 5 |
| Shank Length (LS): | 15 mm |
| Point Length (PL): | 0.73 mm |
| Usable Length (LU): | 15.7 mm |
