Produktinformationen "LSMT0202ZER-HM AH3225|Tungaloy"
Single-sided inserts with 2 edges. High feed inserts. First choice insert for various applications including slotting, pocketing, or for long reach areas.
Eigenschaften
| Application: | High Feed Milling |
|---|---|
| Coating: | TiAlSiCrN |
| Cutting Edge Material: | Carbide |
| Tool Type: | Single sided Inserts |
| Body Material: | Carbide |
| Grade: | AH3225 |
| group_id: | 124 |
| FamilyName: | LSMT-HM |
| product_pic: | 2136 |
| product_drw: | 2136 |
| ToolType: | Insert |
| Unit: | M |
| FamilyPriority: | 48 |
| PackSize: | 10 |
| PricePer: | 1 |
| fixed_lot_multiplier: | 10 |
| product_code: | TUN6778688 |
| ProductName: | LSMT0202ZER-HM AH3225 |
| COO: | JAPAN |
| UOM: | EA |
| hazard_material: | 0 |
| oversize_product: | 0 |
| UNSPSC: | 23242105 |
| FamilyDesc: | Single-sided inserts with 2 edges. High feed inserts. First choice insert for various applications including slotting, pocketing, or for long reach areas. |
| FamilyShortDesc: | Single-sided inserts with 2 edges. High feed inserts |
| Vendor: | 10 |
| Link: | https://www.imc-companies.com/Tungaloy/tcat/e.asp?cat=6778688 |
| Movie: | https://www.youtube.com/watch?v=8GtJOrCHKBo |
| Produktlinie: | TungForceFeed |
| LogoPic1: | 570 |
| InfoPic: | TR521 |
| StockSource: | IMC |
| FamilyBrand: | Tungaloy |
| BrandCode: | TUN |
| BrandName: | Tungaloy |
| APP1: | 550 |
| APP1Name: | High Feed Milling |
| DXF: | 6778688 |
| STP: | 6778688 |
| TechFile1: | TR521 |
| STPL: | NULL |
| Measurement Type: | Metric |
| Applicable Material: | Rostfreier Stahl, Stahl |
| Package Weight: | 0.0000 |
| MSDS: | 07999 |
| LocalField1: | 2 |
| ManufacturerNo: | 6778688 |
| Insert Length (INSL): | 6.4 mm |
| Corner Radius (RE): | 1 mm |
| Cutting Edge Effective Length (LE): | 1.7 mm |
| Depth of Cut Maximum (APMX): | 0.5 mm |
| Maximum Feed per Tooth (fz(max)): | 0.8 mm/tooth |
| Inscribed Circle Diameter (IC): | 4.2 mm |
| Minimum Feed per Tooth (fz(min)): | 0.1 mm/tooth |
| Insert Thickness (S): | 2.3 mm |
| Number of Cutting Edges: | 2 |
