Produktinformationen "LNMX0405ZER-HJ AH3225|Tungaloy"
Double-sided insert with 4 edges for high-feed milling
Eigenschaften
| Application: | High Feed Milling |
|---|---|
| Coating: | TiAlSiCrN |
| Cutting Edge Material: | Carbide |
| Body Material: | Carbide |
| Grade: | AH3225 |
| group_id: | 124 |
| FamilyName: | LNMX-HJ |
| product_pic: | 1712 |
| product_drw: | 1712 |
| ToolType: | Insert |
| Unit: | M |
| FamilyPriority: | 98 |
| PackSize: | 10 |
| PricePer: | 1 |
| fixed_lot_multiplier: | 10 |
| product_code: | TUN6782089 |
| ProductName: | LNMX0405ZER-HJ AH3225 |
| COO: | JAPAN |
| UOM: | EA |
| hazard_material: | 0 |
| oversize_product: | 0 |
| UNSPSC: | 23242105 |
| FamilyDesc: | Double-sided insert with 4 edges for high-feed milling |
| FamilyShortDesc: | Double-sided insert with 4 edges for high-feed milling |
| Vendor: | 10 |
| Link: | https://www.imc-companies.com/Tungaloy/tcat/e.asp?cat=6782089 |
| Movie: | https://www.youtube.com/watch?v=cO0MEoheZvo |
| Produktlinie: | DoTwistBall |
| LogoPic1: | 505 |
| StockSource: | IMC |
| FamilyBrand: | Tungaloy |
| BrandCode: | TUN |
| BrandName: | Tungaloy |
| APP1: | 550 |
| APP1Name: | High Feed Milling |
| DXF: | 6782089 |
| STP: | 6782089 |
| STPL: | NULL |
| Measurement Type: | Metric |
| Applicable Material: | Rostfreier Stahl, Stahl |
| Package Weight: | 0.0000 |
| MSDS: | 07999 |
| LocalField1: | 2 |
| ManufacturerNo: | 6782089 |
| Insert Length (INSL): | 12 mm |
| Corner Radius (RE): | 1.3 mm |
| Cutting Edge Effective Length (LE): | 4.36 mm |
| Depth of Cut Maximum (APMX): | 1.3 mm |
| Insert Width (W1): | 8.2 mm |
| Maximum Feed per Tooth (fz(max)): | 1.3 mm/tooth |
| Inscribed Circle Diameter (IC): | 8.2 mm |
| Minimum Feed per Tooth (fz(min)): | 0.3 mm/tooth |
| Insert Thickness (S): | 5 mm |
| Number of Cutting Edges: | 4 |
