HXN02R008MS05-01|Tungaloy
HXN02R008MS05-01|Tungaloy
Produktinformationen "HXN02R008MS05-01|Tungaloy"
High feed endmill, modular type with TungMeister connection, with 4-corner double sided inserts
Eigenschaften
| Application: | High Feed Milling |
|---|---|
| Tool Type: | Fast Feed Endmill |
| Body Material: | Steel |
| group_id: | 138 |
| FamilyName: | HXN02-S |
| product_pic: | 2780 |
| product_drw: | 2780 |
| ToolType: | Tool |
| Unit: | M |
| FamilyPriority: | 29 |
| PackSize: | 1 |
| PricePer: | 1 |
| fixed_lot_multiplier: | 1 |
| product_code: | TUN6967322 |
| ProductName: | HXN02R008MS05-01 |
| COO: | JAPAN |
| UOM: | EA |
| hazard_material: | 0 |
| oversize_product: | 0 |
| FamilyDesc: | High feed endmill, modular type with TungMeister connection, with 4-corner double sided inserts |
| FamilyShortDesc: | High feed endmill, modular type with TungMeister connection, with 4-corner double sided inserts |
| Vendor: | 10 |
| Link: | https://www.imc-companies.com/Tungaloy/tcat/e.asp?cat=6967322 |
| Produktlinie: | TungMeister High Feed |
| LogoName2: | AddDoFeed |
| LogoPic1: | 1578 |
| Remarks: | Wrench sold separately. |
| LogoPic2: | 575 |
| StockSource: | IMC |
| FamilyBrand: | Tungaloy |
| BrandCode: | TUN |
| BrandName: | Tungaloy |
| APP1: | 550 |
| APP1Name: | High Feed Milling |
| DXF: | 6967322 |
| ICON1: | TH7 |
| STP: | 6967322 |
| STPL: | 6967322 |
| Measurement Type: | Metric |
| Functional Length (LF): | 10 mm |
| Package Weight: | 0.0000 |
| Cutting Diameter (DC): | 3.97 mm |
| MSDS: | 07995 |
| LocalField1: | 2 |
| Connection Retention Knob Thread Size (CRKS): | S05 |
| ManufacturerNo: | 6967322 |
| Master Insert Identification (MIID): | LNMU0202ZER-MM |
| Overall Length (OAL): | 17.1 mm |
| Shank Height (H): | 5.5 mm |
| Cutting Diameter (DC/DCX): | 3.97 mm |
| Cutting Item Count (CICT): | 1 |
| Depth of Cut Maximum (APMX): | 0.5 mm |
| Cutting Diameter Maximum (DCX): | 8 mm |
| Tool Cutting Edge Angle (KAPR): | 17 Degrees |
