YDEN0603PDSR-D DX110|Tungaloy
YDEN0603PDSR-D DX110|Tungaloy
Produktinformationen "YDEN0603PDSR-D DX110|Tungaloy"
PCD regular inserts with wiper
Eigenschaften
| Application: | Face Milling |
|---|---|
| Coating: | Uncoated |
| Cutting Edge Material: | PCD |
| Tool Type: | Single sided Inserts |
| Body Material: | Carbide |
| group_id: | 124 |
| FamilyName: | YDEN0603PD(F/S)R-D |
| product_pic: | 2168 |
| product_drw: | 2168 |
| ToolType: | Insert |
| Unit: | M |
| FamilyPriority: | 251 |
| PackSize: | 1 |
| PricePer: | 1 |
| fixed_lot_multiplier: | 1 |
| product_code: | TUN6777421 |
| ProductName: | YDEN0603PDSR-D DX110 |
| COO: | JAPAN |
| UOM: | EA |
| hazard_material: | 0 |
| oversize_product: | 0 |
| FamilyDesc: | PCD regular inserts with wiper |
| FamilyShortDesc: | PCD regular inserts with wiper |
| Movie: | https://www.youtube.com/watch?v=6fTUnuz3RDk |
| Vendor: | 20 |
| Link: | https://www.imc-companies.com/Tungaloy/tcat/e.asp?cat=6777421 |
| Produktlinie: | TungSpeedMill T/EPYD06 |
| LogoPic1: | 583 |
| StockSource: | IMC |
| FamilyBrand: | Tungaloy |
| BrandCode: | TUN |
| BrandName: | Tungaloy |
| APP1: | 553 |
| APP1Name: | Face Milling |
| DXF: | 6777421 |
| STP: | 6777421 |
| STPL: | NULL |
| Measurement Type: | Metric |
| Applicable Material: | Nicht Eisen Werkstoffe |
| Package Weight: | 0.0000 |
| MSDS: | 07999 |
| LocalField1: | 2 |
| ManufacturerNo: | 6777421 |
| Insert Length (INSL): | 12.7 mm |
| Cutting Edge Effective Length (LE): | 6.5 mm |
| Depth of Cut Maximum (APMX): | 4.5 mm |
| Insert Width (W1): | 9.5 mm |
| Maximum Feed per Tooth (fz(max)): | 0.2 mm/tooth |
| Wiper Edge Length (BS): | 2.2 mm |
| Insert Thickness (S): | 3.1 mm |
| Minimum Feed per Tooth (fz(min)): | 0.05 mm/tooth |
| Number of Cutting Edges: | 1 |
| Grade: | DX110 |
| UNSPSC: | 23242105 |
