Produktinformationen "XVCT160508PEFR-AM TH10|Tungaloy"
Insert with AM chipbreaker for aluminum machining
Eigenschaften
| Application: | Shoulder Milling |
|---|---|
| Coating: | Uncoated |
| Cutting Edge Material: | Carbide |
| Tool Type: | Mill AL, HTA Geometric Inserts |
| Body Material: | Carbide |
| Grade: | TH10 |
| group_id: | 124 |
| FamilyName: | XVCT16-AM |
| product_pic: | 2728 |
| product_drw: | 2728 |
| ToolType: | Insert |
| Unit: | M |
| FamilyPriority: | 336 |
| PackSize: | 10 |
| PricePer: | 1 |
| fixed_lot_multiplier: | 10 |
| product_code: | TUN6967070 |
| ProductName: | XVCT160508PEFR-AM TH10 |
| COO: | SOUTH KOREA |
| UOM: | EA |
| hazard_material: | 0 |
| oversize_product: | 0 |
| UNSPSC: | 23242105 |
| FamilyDesc: | Insert with AM chipbreaker for aluminum machining |
| FamilyShortDesc: | Insert with AM chipbreaker for aluminum machining |
| Vendor: | 20 |
| Link: | https://www.imc-companies.com/Tungaloy/tcat/e.asp?cat=6967070 |
| Produktlinie: | TungAluMill |
| LogoPic1: | 523 |
| Remarks: | XVCT AM inserts can be used either with a TPXV/EPXV cutter or TPV/EPV cutter. |
| StockSource: | IMC |
| FamilyBrand: | Tungaloy |
| BrandCode: | TUN |
| BrandName: | Tungaloy |
| APP1: | 556 |
| APP1Name: | Shoulder Milling |
| DXF: | 6967070 |
| STP: | 6967070 |
| STPL: | NULL |
| Measurement Type: | Metric |
| Applicable Material: | Guss, Harte Werkstoffe, Hochlegierte Werkstoffe, Nicht Eisen Werkstoffe |
| Package Weight: | 0.0000 |
| MSDS: | 07999 |
| LocalField1: | 2 |
| ManufacturerNo: | 6967070 |
| Insert Length (INSL): | 22.2 mm |
| Corner Radius (RE): | 0.8 mm |
| Wiper Edge Length (BS): | 1.1 mm |
| Depth of Cut Maximum (APMX): | 16 mm |
| Insert Width (W1): | 11.2 mm |
| Maximum Feed per Tooth (fz(max)): | 0.35 mm/tooth |
| Minimum Feed per Tooth (fz(min)): | 0.07 mm/tooth |
| Insert Thickness (S): | 5.5 mm |
| Number of Cutting Edges: | 2 |
