TDX340F40-2|Tungaloy
TDX340F40-2|Tungaloy
Produktinformationen "TDX340F40-2|Tungaloy"
TungDrillTwisted Indexable insert drills, L/D=2, Flat cotter
Eigenschaften
| Application: | General Drilling |
|---|---|
| Tool Type: | Indexable Insert Drills |
| Body Material: | Steel |
| group_id: | 6216 |
| FamilyName: | TDX-F L/D=2 |
| product_pic: | 1575 |
| product_drw: | 1575 |
| ToolType: | Tool |
| Längen/Durchmesser Verhältnis: | 2xD |
| Unit: | M |
| FamilyPriority: | 35 |
| PackSize: | 1 |
| PricePer: | 1 |
| fixed_lot_multiplier: | 1 |
| product_code: | TUN6718426 |
| ProductName: | TDX340F40-2 |
| COO: | JAPAN |
| UOM: | EA |
| hazard_material: | 0 |
| oversize_product: | 0 |
| UNSPSC: | 23242106 |
| FamilyDesc: | TungDrillTwisted Indexable insert drills, L/D=2, Flat cotter |
| FamilyShortDesc: | TungDrillTwisted Indexable insert drills, L/D=2, Flat cotter |
| Vendor: | 360 |
| Link: | https://www.imc-companies.com/Tungaloy/tcat/e.asp?cat=6718426 |
| Produktlinie: | TungDrill Twisted |
| LogoPic1: | 630 |
| StockSource: | IMC |
| FamilyBrand: | Tungaloy |
| BrandCode: | TUN |
| BrandName: | Tungaloy |
| APP1: | 650 |
| APP1Name: | General Drilling |
| DXF: | 6718426 |
| ICON1: | TH7 |
| STP: | 6718426 |
| STPL: | 6718426 |
| Measurement Type: | Metric |
| Connection Diameter Machine Side (DCONMS): | 40 mm |
| Functional Length (LF): | 98.6 mm |
| Package Weight: | 1.2600 |
| Cutting Diameter (DC): | 34 mm |
| MSDS: | 07995 |
| LocalField1: | 2 |
| ManufacturerNo: | 6718426 |
| Master Insert Identification (MIID): | XPMT110412R-DJ |
| Flange Diameter (DF): | 50 mm |
| Overall Length (OAL): | 168.7 mm |
| Length Chip Flute (LCF): | 73.7 mm |
| Cutting Diameter Maximum (DCX): | 34 mm |
| Cutting Diameter Minimum (DCN): | 34 mm |
| Shank Length (LS): | 69 mm |
| Point Length (PL): | 1.08 mm |
| Usable Length (LU): | 69.1 mm |
